Altimeters

Ladies and gentlemen, we are now cruising at 10,000 meters. Next time you hear your pilot say words like these, stop to ask yourself one question: how on Earth do they know? It's not as if a plane is like a car, easily able to keep track of how far its wheels have rolled along the ground. Indeed, there's no simple way to know how far you've flown at all (unless you know your equations of motion). How, then, does a pilot measure a plane's height in the air? Simple! Using a handy gadget called an altimeter. Let's take a closer look at what these things are and how they work!

Photo: The Alti-2 MA2-30 altimeter, popular with parachutists, used an analog (pointer and dial) display. This one is being worn by a marine about to make a parachute drop from 10,000 feet. Not everyone wants to wear an altimeter all the time, however, and altimeter watches with digital LCD displays, such as those made by Suunto, are more popular with hikers and mountain climbers. Some use built in barometers; others rely on GPS. Photo by Lance Cpl. Harley Robinson courtesy of US Marine Corps.

Sponsored links

Contents

  1. Why does altitude matter?
  2. Pressure altimeters—a closer look
  3. Radio altimeters
  4. GPS altimeters
  5. Laser altimeters
  6. Find out more

Why does altitude matter?

You might not think it matters very much whether pilots know how high in the air they're flying; after all, they can always peer through the windows! But measuring altitude (your height above sea level) is much more important to a pilot than you might think. Some of Earth's mountain ranges are surprisingly high and harder to miss in bad weather than you might suppose. Mount Everest, for example, is an amazing 8.8 km (5.5 miles) above sea level, so flying at 10,000 meters (6.2 miles) doesn't give you that much room to maneuver. Then there are other planes to avoid. And it's actually more efficient to fly at higher altitudes where the air is thinner and overcoming air resistance uses less fuel. All told, there are plenty of good reasons for flying high. But how high, exactly?

There are two main ways to measure altitude accurately. One is to measure the air pressure and figure altitude out from that. The other is to bounce a radio beam down from your plane and time how long it takes to reflect back up again.

Hercules airplane flying low over forest.

Photo: Flying an airplane for a cargo drop is a tricky operation. The altimeter, which measures your height above sea-level, is only one of dozens of instruments you have to keep an eye on, especially if you're flying low. But how low is too low? This plane is getting ready to release supplies over Fais Island—and accurate altitude measurement is absolutely critical. Photo by Osakabe Yasuo courtesy of US Air Force and Wikimedia Commons.

Pressure altimeters—a closer look

Close up of an aneroid barometer showing the dial and the spring inside.

Photo: A pressure altimeter is a more sophisticated version of an aneroid barometer, like this. Instead of showing the pressure on the dial, it shows height—but that's okay because there is an exact correlation between the two.

Why do we have air pressure? Earth's gravity pulls everything toward it—and everything includes even the smallest things you can imagine, like molecules of air. If you're an air molecule near the ground, you've got lots of other air molecules above you pushing and squashing you down; higher up, there are fewer molecules and there's less pushing. That's why air pressure is highest at Earth's surface and gradually falls, in a systematic way, the higher up you go. Measuring the air pressure is therefore (in theory, at least) a simple and effective way of measuring altitude.

The altimeters onboard most planes are actually aneroid barometers (pressure-measuring instruments) that have been calibrated (marked with a scale) so they show height instead of pressure. Like normal aneroid barometers, they consist of a hollow, sealed box that expands (as the pressure falls) or contracts (as the pressure rises). As the box changes size, by very tiny amounts, an intricate system of levers and gears magnifies its movements and makes a pointer rotate on a dial marked with height measurements. Hey presto, tiny changes in air pressure become accurate measurements of altitude.

Patent diagram fo a typical pressure altimeter showing the main parts inside.

Photo: How a pressure altimeter works: This is a typical pressure altimeter from the 1930s by Victor Carbonara of the Bendix Aviation Corporation. Looking from the side, you can see a sealed, air-filled box (red) that expands or contracts according to changes in pressure. Its movements are amplified by a system of linkages and levers (blue) and a gear mechanism (green), which operates the altimeter pointers. Now looking at the diagram on the right, we can see how the altitude is displayed by moving pointers on a dial (brown), calibrated in hundreds and thousands of feet. This diagram is from US Patent #2,099,466: Altimeter, courtesy of US Patent and Trademark Office.

Altimeters that work this way measure height by measuring the pressure compared to sea-level, but that's not the only thing that causes pressure variations on Earth. Air pressure is constantly fluctuating across Earth's surface due to changes in the weather—so temperature and pressure differences both have to be allowed for if pressure-based altimeters are to work accurately. Another drawback of pressure-based altimeters is that they don't take account of dangerous obstacles such as buildings and power lines. (You can read much more about this, and how to use altimeters safely in practice, in the FAA Pilot's Handbook of Aeronautical Knowledge, "Chapter 8: Flight Instruments".) Differences in temperature also introduce errors. If you're flying in colder air, your pressure altimeter will tend to give an altitude reading that is somewhat too high compared to flying in warmer air. (You'll find a clear explanation of why in an old book by the US Department of Defense called Meteorology for Naval Aviators, pages 3-6 to 3-8, which is free to read on that link.)

Who invented them?

Pressure altimeters were invented in the 1920s by German-born engineer Paul Kollsman, who was granted US Patent #2,036,581: Level flight indicator in April 1936. The very first one made its debut on September 24, 1929 in a pioneering "instrument flight" by Lieutenant General James H. "Jimmy" Doolittle.

Sponsored links

Radio altimeters

Radio altimeters don't suffer from these problems. They're simpler and work in a similar way to radar (the system planes, ships, and other vehicles use to navigate): they just fire a beam of radio waves down from the plane and wait for the reflections to return. Since radio waves travel at the speed of light (300,000 km or 186,000 miles each second), it takes only a few hundredths of a second for a radio beam to make the 20,000-meter or so round trip to Earth's surface and back. The plane times the beam and calculates its altitude in kilometers by multiplying the time in seconds by 150,000 (that's 300,000 divided by two: don't forget the beam has traveled twice as far as its own altitude going to the ground and back again). Radio altimeters are much quicker and more precise than pressure instruments and are widely used in high-speed airplanes or ones that need to fly at particularly low altitudes, such as jet fighters.

A radio altimeter measures height by bouncing a radio beam off the ground below.

Photo: How a radio altimeter works. The speed of light is about a million times faster than the cruising speed of a typical plane (v), so a radio signal bounced to the ground and back travels a distance of about twice the plane's altitude (2h). That means you can find the altitude by multiplying the time the signal takes to go from the transmitter (red circle) to the receiver (orange circle) by half the speed of light. In theory, the faster the plane travels, the less accurate the measurement, because the radio beam has further to travel; in practice, the speed of light is so much faster than the speed of the plane that any error is minimal.

Radio altimeters like this were first used in October 1938, developed by a coalition of Bell Laboratories, Western Electric, United Air Lines, and Boeing, and originally went by the rather grandiose name "terrain clearance indicators." Although the makers boasted that "the new device operates by radio, using the shortest wave ever employed for aviation," the 500Mhz waves they used were actually short-wavelength microwaves (with a shorter wavelength and higher frequency than "proper" radio waves).

The original Western Electric/Bell Laboratories radio altimeter from 1938.

Photo: The dipole (rod-like) antenna from the original, Western Electric 1938 radio altimeter hanging beneath a plane. Judging by the photo this came from, the antenna was about 20–30cm across and hung beneath the plane's fuselage, aiming straight down. Photo by Harris & Ewing courtesy of US Library of Congress.

Radio altimeters are also known as radar altimeters; typically, they now use high radio wave frequencies of several gigahertz (so wavelengths roughly 10cm or 4in long), similar to those used in microwave ovens, which is much higher than the AM (in the kilohertz) or FM (megahertz) radio range. NASA has been mapping the ocean surface with space-based radar altimeters since 1992, when it launched the original TOPEX/Poseidon ocean-mapping satellite. Follow-on satellites Jason-1 and Jason-2 carried on the work; NASA's Ocean Surface Topography project continues today with the Jason-3 satellite, shown below.

Jason-3 satellite mapping the ocean surface with radar altimetry.

Artwork: NASA's Jason-3 satellite maps the ocean surface using a space-based radar altimeter. Artwork courtesy of NASA.

GPS altimeters

There are at least two more ways of measuring altitude, but they're not widely used on airplanes. One method is to use GPS (global positioning system) signals from navigation satellites in space. In much the same way that GPS signals from three satellites can be used to pinpoint your position on Earth's surface (as explained in our main article on how GPS works), using signals from four or more satellites lets you calculate your height above Earth as well. Unfortunately, GPS altitude measurements are not as accurate as those made with conventional altimeters, so they're not likely to replace existing technologies on airplanes anytime soon.

Laser altimeters

Another way of measuring altitude involves shining laser beams of infrared light down from a plane, helicopter, or satellite and calculating the time to return, much like using radio and radar. The reflected beam is collected by mirrors and lenses and focused on a photocell detector sensitive to infrared light. As the aircraft flies along, it systematically measures its altitude and plots what's called a topographical map of the surface contours beneath it. This technique is called laser altimetry or LIDAR (light detection and ranging) and it has been widely used by space probes to map surface features on other planets. NASA's Mars Orbiter Laser Altimeter (MOLA) works this way. (Read more about this in our separate article on LIDAR.)

Topographical maps of Mars made by the Mars Orbiter Laser Altimeter (MOLA) in 2001.

Photo: These topographical maps of the surface of Mars were made in 2001 by NASA's MOLA space probe, using laser altimetry. Red, orange, and yellow areas are mountains; green, blue, and violet areas are craters. Photo by courtesy of NASA Jet Propulsion Laboratory (NASA-JPL).

Sponsored links

Don't want to read our articles? Try listening instead

If you'd rather listen to our articles than read them, please subscribe to our new podcast on Apple Podcasts, Spotify, Audible, Amazon, Podchaser, or your favorite podcast app, or listen below:

Find out more

On this website

Books

Articles

Patents

If you're interested in more technical details of how altimeters work, the following patents are worth a look. This is just a quick, representative selection to give you an idea of pressure, radio, and laser altimeters and how they compare:
